"AOLITE" brand TH2506 diesel telehandler
— Reach High, Lift Heavy
5850mm maximum lift height with 2500kg lift capacity perfect for pallet stacking, truck loading, and high-level unloading in warehouses and construction sites.
— Work in Tight Spaces with Ease
Three steering modes (front / four wheel / crab) with only 3310mm turning radius moves freely through narrow alleys, workshops, and storage yards without scraping.
— Four-Wheel Drive, No More Getting Stuck
Hydraulic torque converter four wheel drive 380mm ground clearance keeps you moving through mud, sand, and wet job sites without getting stuck.
— Multiple Engine Options for Global Standards
Optional engines: Changchai (55kW), Kohler KDI (55kW), Cummins QSF2.8 (55kW) meets Euro V and EPA4 standards for worry free export.
| Maximum lift capacity | 2500kg |
| Lift capacity to full height | 2000kg |
| Lift capacity at full reach | 800kg |
| Lift height | 5850mm |
| Bucket lifting force | 4205N |
| Reach at maximum lift height | 450mm |
| Maximum forward reach | 3300mm |
| Weight unload | 5500kg |
| Tyre | 12-16.5 |
| Outside turn radius(over tyre) | 3310mm |
| Overall height | 2000mm |
| Overall width(over tyre) | 2000mm |
| Inside width of cab | 800mm |
| Front track | 1480mm |
| Wheelbase | 2300mm |
| Overall length to front carriage | 3900mm |
| Ground clearance | 380mm |
| Engine brand | YUNNEI/YN27GBZ |
| Engine rate power | 58KW |
| Optional engine |
EURO5 standard: CHANGCHAI (55KW) EPA4/EURO5 standard:KOHLER KDI2504TCR(55KW) EPA4 standard: CUMMINS QSF2.8(55KW) |
| Pallet fork length | 1220mm |
| Hydraulic oil tank | 115L |
| Diesel tank | 63L |
| Transmission type | hydraulic torque converter |
| Steering type | Front Wheel SteeringFour Wheel SteeringCrab Steering |
| Drive type | 4 wheel drive |
AOLITE Brand TH2506 diesel mini telehandler package:
-- 1 set in 1*20GP container
-- 3 sets in 1*40HQ container
